Description

Delfield 8191-EFNP Details

The Delfield 8191-EFNP narrow four pan drop in LiquiTec cooled food well is a dependable way to present salad, fruit, gelatin desserts, and other cold foods at your buffet line! This cold food well incorporates LiquiTec cooling technology, a unique system which works by using eutectic fluid sealed in a jacket within the pan dividers, cooling each pan with more contact points and a much larger surface area than traditional refrigerant line models. The end result is consistent, even cooling, fewer compressor cycles, and better energy efficiency than comparable cold food wells! Because of how this food well holds pans, it’s great for narrower countertops or two-sided buffet setups where you’d want to display the pans lengthwise.

This refrigerated cold food well can hold four full size 12″ x 20″ food pans up to 6″ deep lengthwise at food safe holding temperatures for an extended period of time. To maintain a consistent temperature, the bottom-mounted 1/4 hp compressor circulates eco-friendly R290 refrigerant to cool the LiquiTec fluid, which evenly chills the contents of the well. This specialized refrigerant has an ozone depletion potential (ODP) of 0 and a global warming potential (GWP) of 3, making it an environmentally-responsible choice for your business. A bottom-mounted 1/2″ stainless steel drain and manifold collect condensation.

This stainless steel drop-in refrigerated cold food well is insulated with high-density foam that guarantees superior temperature retention, and an included press fit top gasket allows you to snugly install this food well into your countertop. This narrow drop-in refrigerated cold food well requires a 90″ x 17 1/4″ cutout.

Overall Dimensions:
Left to Right: 90 7/8″
Front to Back: 18″
Height (including compressor): 23 1/4″

Cutout Dimensions:
Width: 90″
Depth: 17 1/4″
